Description

Physical
Contact Material	Cadmium, Silver
Mount	PCB, Through Hole
Number of Pins	8
Technical
Ambient Temperature Range High	70 °C
Coil Current	21.8 mA
Coil Power	530 mW
Coil Resistance	1.1 kΩ
Coil Type	Non-Latching
Coil Voltage (DC)	12 V
Contact Current Rating	5 A
Current Rating	5 A
Max Current Rating	10 A
Max Operating Temperature	70 °C
Max Voltage Rating (AC)	380 V
Max Voltage Rating (DC)	125 V
Manufacturer Package Identifier	G2R-2-DC24
Min Operating Temperature	-40 °C
Number of Contacts	2
Operate Time	15 ms
Power Consumption	530 mW
Power Rating	530 mW
Relay Type	General Purpose
Release Time	5 ms
Switching Current	5 A
Termination	PC Pin
Throw Configuration	DPDT
Voltage Rating (AC)	250 V
Voltage Rating (DC)	30 V
Dimensions
Depth	13 mm
Height	25.5 mm
Length	29 mm
Width	13 mm
